GSM/WCDMA Farm Weather Station

Description

FEATURES

• It can send data to the web (www.wunderground.com) by WCDMA/GSMso that users can run remote monitoring of weather condition, through this website.
• It can connect to PCvia USB cable to view the history data. (PC software is available).
• It can send the SMS (message)to your mobile phone, about the weather status (interval: can be adjusted). And it can send the alarming message your mobile phone.
• It support mirco sim cardor Nano sim card. 3G module supports: 800/850/900/1900/2100Mhz@UMTS, 850/900/1800/1900Mhz@GSM.
• The data will be saved as CSV formatinto the TF card (micro SD card).
• Outdoor/indoor humidity/temperature
• Display wind speed, gust andwind direction
• Wind speedin ms, km/h, mph, knots and bft
• Rainfallin inch, mm
• Pressuredisplay with hpa, mmhg or inhg unit.

SPECIFICATION

• Outdoor data
• Transmission distance: Max. 100meter(330 feet)
• (tested in open field, no obstacle in between, no interfere in between)
• Frequency: 433 MHz
• Temperaturerange: -40～+60°C
• Accuracy: +/- 1˚C
• Resolution: 0.1˚C
• Humidityrange:1%～99%
• Accuracy: +/- 5%
• Rainvolume:0 – 9999 mm
• Resolution:0.3mm (if rain volume < 1000mm), 1mm (if rain volume > 1000mm)
• Accuracy: +/- 10%
• Wind speed : 0-50m/s (0~100mph)
• Accuracy: +/- 1m/s (wind speed< 5m/s), +/-10% (wind speed > 5m/s)
• Winddirection: 0 to 359 degree
• Light: 0-200k Lux
• Accuracy: +/-15%
• Measuring interval outdoor sensor: 16 sec
• Water proof lever: IPX3

Indoor data

• Indoor temperature:0˚C–60˚C
• Resolution: 0.1˚C
• Accuracy: +/-1˚C
• Humidity: 10%～99%
• Resolution: 1%
• Accuracy: +/- 5%
• Air pressure: 300-1100hPa (8.85-32.5inHg)
• Accuracy: +/-3hpa (@700-1100hpa)
• Resolution: 0.1hPa (0.01inHg)
• Measuring intervalindoor sensor: 61 sec

Power requirement:

• Base station: 18650 lithium rechargeable battery X1 unit.
• Solar panel (Voc:6.2v, Isc:500Ma, size: 195*138*17mm)
• Indoor sensor: 2XAA batteries (not included in the package)
• Outdoor sensor: 2XAA 1.5v non-rechargeable batteries (not included in the package)
