GSM/WCDMA Farm Weather Station


It can send data to the web ( by WCDMA/GSM so that users can run remote monitoring of weather condition, through this website.



  • It can send data to the web ( by WCDMA/GSMso that users can run remote monitoring of weather condition, through this website.
  • It can connect to PCvia USB cable to view the history data. (PC software is available).
  • It can send the SMS (message)to your mobile phone, about the weather status (interval: can be adjusted). And it can send the alarming message your mobile phone.
  • It support mirco sim cardor Nano sim card. 3G module supports: 800/850/900/1900/2100Mhz@UMTS, 850/900/1800/1900Mhz@GSM.
  • The data will be saved as CSV formatinto the TF card (micro SD card).
  • Outdoor/indoor humidity/temperature
  • Display wind speed, gust andwind direction
  • Wind speedin ms, km/h, mph, knots and bft
  • Rainfallin inch, mm
  • Pressuredisplay with hpa, mmhg or inhg unit.


  • Outdoor data
  • Transmission distance: Max. 100meter(330 feet)
  • (tested in open field, no obstacle in between, no interfere in between)
  • Frequency: 433 MHz
  • Temperaturerange: -40~+60°C
  • Accuracy: +/- 1˚C
  • Resolution: 0.1˚C
  • Humidityrange:1%~99%
  • Accuracy: +/- 5%
  • Rainvolume:0 – 9999 mm
  • Resolution:0.3mm (if rain volume < 1000mm), 1mm (if rain volume > 1000mm)
  • Accuracy: +/- 10%
  • Wind speed : 0-50m/s (0~100mph)
  • Accuracy: +/- 1m/s (wind speed< 5m/s), +/-10% (wind speed > 5m/s)
  • Winddirection: 0 to 359 degree
  • Light: 0-200k Lux
  • Accuracy: +/-15%
  • Measuring interval outdoor sensor: 16 sec
  • Water proof lever: IPX3

Indoor data

  • Indoor temperature:0˚C–60˚C
  • Resolution: 0.1˚C
  • Accuracy: +/-1˚C
  • Humidity: 10%~99%
  • Resolution: 1%
  • Accuracy: +/- 5%
  • Air pressure: 300-1100hPa (8.85-32.5inHg)
  • Accuracy: +/-3hpa (@700-1100hpa)
  • Resolution: 0.1hPa (0.01inHg)
  • Measuring intervalindoor sensor: 61 sec

Power requirement:

  • Base station: 18650 lithium rechargeable battery X1 unit.
  • Solar panel (Voc:6.2v, Isc:500Ma, size: 195*138*17mm)
  • Indoor sensor: 2XAA batteries (not included in the package)
  • Outdoor sensor: 2XAA 1.5v non-rechargeable batteries (not included in the package)
